| 订货号 | 型号 | 一般 发货日 | 缸径 | 油缸行程 | 最高容许压力(Mpa) | 使用温度范围(℃) | 使用速度范围(mm/sec) |
|---|---|---|---|---|---|---|---|
| 219133 | TC8R-SA-C-1SA32B100N10-2C | 32mm | 10mm | 12.8 | -10～60 | 8～100 | |
| 219134 | TC8R-SA-C-1SA40B100N15-2C | 40mm | 15mm | 12.8 | -10～60 | 8～100 | |
| 219135 | TC8R-SA-C-1SA50B100N20-2C | 50mm | 20mm | 12.8 | -10～60 | 8～100 | |
| 219136 | TC8R-SA-C-1SA63B100N25-2C | 63mm | 25mm | 12.8 | -10～60 | 8～100 | |
| 219137 | TC8R-SA-C-1SA80B100N30-2C | 80mm | 30mm | 12.8 | -10～60 | 8～100 | |
| 219138 | TC8R-SA-C-1SA100B100N35-2C | 100mm | 35mm | 12.8 | -10～60 | 8～100 | |
